Studiomaster AC36II digitalni analogni procesor
Maloprodajna cena - MPC
RSD62.540,00
Cena sa popustom za plaćanje odmah ili gotovinsko - GOT
RSD56.286,00
(sve cene su sa uračunatim PDVom)
Na zalihama
SKU: AC36II
Načini plaćanja i dostava
Cene na našem sajtu variraju u odnosu na načine plaćanja. Cene na svakom proizvodu prikazane su na dva načina:
MPC – maloprodajna cena artikla
GOT – gotovinsko plaćanje (plaćanje gotovinom u maloprodaji, plaćanje karticom preko sajta odjednom, plaćanje pouzećem, plaćanje uplatnicom, plaćanje po predračunu)
Dostava je besplatna za online narudžbine fizičkih lica u vrednosti preko 15.000,00 dinara. Svaka pošiljka može biti osigurana dodatno/pošiljke do 70 000 dinara su osigurane.
Cenovnik dostave
Klikom na link posetićete stranicu sa ažuriranim cenovnikom kuriskih službi.
Opis proizvoda
Studiomaster AC36II digitalni analogni procesor
je pogodno za manji sistem ozvučenja i studio monitoring.
- Poseduje 3 ulaza i 6 izlaza.
- Input procesuje Gain, Mute, Link, High-cut, Low -cut, Noise gate, 5PEQ, Phase, Delay
- Output procesuje Crossover, 6PEQ, Gain, Mute, Compressor/Limiter, Phase, Delay, Link.
- Frekvencijski odziv: 20Hz~20kHz.
Tehničke specifikacije proizvoda
- System Specification: Frequency Response: 20Hz~20kHz, -0.3dBu, S/N Ratio: >110 dBu, Distortion(THD): <0. 01at1kHz(0dBu), Cross-talk: <100dB below full scale
- Input Section: Type: Balanced XLR, Max. Input Level: +15dBu, Impedance: 1M/ΩStereo; 500kΩ/MONO
- Output Section: Type: Balanced XLR, Max. Output Level (bypass): +15dBu, Impedance: <500Ω
- Digital Processing: 24-bit sigma – delta converters, 48kHz Sampling Rates
- Display: 20x2LCD Display For Parameters Setting And Function Select
- Power Supply: AC~95V-264V FUSE 250VAC/2A FAST
- Dimension (LxWxH):82x205x44CM
- Weight:2.88kg
- 48kHz sampling rate, 40-bit DSP processor, 24-bit AD/DA convertor.
- Input processing includes Gain, Mute, Link, High-cut, Low -cut, Noise gate, 5PEQ, Phase, Delay.
- Output processing includes Crossover, 6PEQ, Gain, Mute, Compressor/Limiter, Phase, Delay, Link.
- Every input and output can do matrix assign freely.
- Adjustable PEQ frequency, Gain and Bandwidth, the gain step is 0.1dB, we can choose style: Peak, H-shelf, L-shelf, LP-6dB, LP-12dB, HP-6dB, HP-12dB.
- The style of all High-cut, Low-cut filter and Distributor Unit: Butterworth, Linkwitz- Riley, Bessel, Slope is-6dB/oct ~-48dB/oct. Adjustable compressormiter threshold, soft knee, ratio, attached time and release time. Noise gate’s threshold, hold time, attached time and release time can be adjustment.
- The parameters of input and output adjusting are linkable, revisable input and output channels.
- All delay module’s delay time can reach over 680ms the step is: 0.021ms.
- Parameter setting of each channel can copy freely, build-in signal generator.
- Input and Output on the front panel are equipped with 5-segment high precision level indicators, key indicators, security protection function.
- 30 user preset, 1factory preset, device parameter and single preset file can save in computer; it also can download from computer and save in the device. The device itself can store multiple preset parameters and recall freely. With PC software, one-key online made the operation more convenient.
- USB and RS232 controlling ports, Online remote control and 255 units linkable through Rs485.
